RAJINDRA MILLING HEAD



Technical Specification Of Milling Head

Model
3 kw
5 kw
7.5 kw
10 kw
15 kw
Spindle Taper
ISO - 40
ISO - 40
ISO - 50
ISO - 50
ISO -50
Taper Speeds
6 No.
9 No.
9 No.
9 No.
12 No.
Speeds Range
70 to 400 rpm
57 to 368 rpm
45 to 300 rpm
45 to 340 rpm
45 to 370 rpm
Quil Travel
100 mm
100 mm
130 mm
130 mm
150 mm
Spindle Dia.
80 mm
85 mm
100 mm
120 mm
150 mm
Head Swivel
±45º
±45º
±45º
±45º
±45º

Specifications are subject to alteration and improvement without notice.
