RAJINDRA EXTRA HEAVY PLANO MILLER (2500-15000 mm)



See Working of Our Machines
See Working of Our Machines

Technical Specification Of Plano Miller Machine

Model
Units
RPM3
RPM5
RPM6
RPM8
RPM9
RPM15
Table Lenght
mm
3000
5000
6000
8000
9000
15000
Table Width
mm
900-3000
Max Job Height
mm
1000-3000
Max Job Width
mm
1000-5000
Bed Lenght
mm
6000
10000
12000
16000
18000
30000

Milling Head
No. of Speeds
6
Range of Speeds RPM
30-500
Motor Power HP
5-7.5-10-15-20

Feed Gear Box HP
5-50
Range of Speeds Per/Min.
50-150 mm
No. of Speeds
6+1 Rapid

Cross Feed Gear
HP
2-5
No. of Cross Feeds
6+1 Rapid
Cross Slide Lift Motor
HP
2-7.5
Standard Accessories
»
Automatic Lubrication to 'v' guides.
»
Provided with automatic lifting arrangement for easy and quick movement of cross slide.
»
Single Millin Head on cross Slide.
»
Equipped with electric panel and motor.
Special Accessories
»
Extra Milling Head, Fead Gear Box

Specifications are subject to alteration and improvement without notice.
